| Model | Reolink Duo 2 PoE PCDUOB4K01 |
| Resolution | 4K Ultra HD (Dual-Lens) |
| Night Vision | Infrared LEDs with up to 30m range |
| Motion Detection | AI-powered human and vehicle detection |
| Viewing Angle | Ultra-wide dual-lens coverage |
| Remote Access | Yes, via Reolink App (iOS & Android) |
| Storage Options | MicroSD card, NVR storage & Cloud backup |
| Power Source | Power Adapter / PoE (Power over Ethernet) |
| Weather Resistance | IP66 – Suitable for outdoor use |
| Approximate Weight | 1.6kg |
Reolink Duo 2 PoE – 4K Dual-Lens Security Camera
The Reolink Duo 2 PoE delivers ultra-wide 180° panoramic security in brilliant 4K UHD resolution. Its dual-lens design stitches two 2K streams into a seamless single panorama — perfect for wide-area surveillance with minimal blind spots.
Key Features
- 4K UHD & 180° Panorama – Dual 1/2.7″ CMOS sensors (f/2.0, 3.2 mm) record at 4608×1728 @ 20 fps for wide, clear coverage.
- Day & Night Vision – Color night vision with integrated spotlights (560 lm) or IR night mode up to 30 m with 6× IR LEDs.
- Smart Detection – Profiles people, vehicles, and pets with smart alerts; reduces false alarms without monthly fees.
- Two-Way Audio – Built-in microphone and speaker let you speak or warn visitors.
- PoE Power – IEEE 802.3af (48 V) simplifies installation using a single cable for power and data.
- Flexible Local Storage – Supports microSD cards up to 256 GB, FTP/NAS, Reolink NVR, or Home Hub setups.
- Weatherproof Build – IP66/IP67-rated housing stands up to rain, heat, and cold environments.
- Time-Lapse Mode – Capture sunrise, construction, or events in panoramic timelapse videos.
Detailed Specifications
| Parameter | Details |
|---|---|
| Image Sensor | 1/2.7″ CMOS |
| Resolution & Frame Rate | 4608×1728 (8 MP) @ 20 fps |
| Lens | Fixed, f = 3.2 mm, F = 2.0 |
| Field of View | Horizontal 180° • Vertical 60° |
| Night Vision | IR up to 30 m (850 nm), or spotlight color at 560 lm |
| Video Compression | H.265 / H.264 |
| Audio | Two-way (mic + speaker) |
| Power | PoE (IEEE 802.3af, <12 W) & optional DC 12 V/2 A |
| Storage | microSD up to 256 GB; FTP/NAS; Reolink NVR/Home Hub |
| Durability | IP66/IP67 outdoor-rated |
| Operating Temp/Humidity | -10 °C to 55 °C • 10–90 % RH |
In the Box
- Reolink Duo 2 PoE camera unit
- Mounting template, screws, waterproof RJ45 lid
- 1 m network cable (test use only)
- Quick-start guide
